Module Type:Remote Rack Interface Module
Compatibility:Supported with Allen-Bradley ControlLogix and CompactLogix PLCs
Communication Protocol:Ethernet/IP
Power Requirements:12-24 V DC
Operating Temperature Range:-40°C to 85°C
Operating Humidity Range:5% to 95% non-condensing
Data Transfer Rate:10/100 Mbps
LED Display:4-character alphanumeric scrolling LED display
Web Server:Internal web server for documentation and diagnostics
Software Support:ProSoft Configuration Builder (PCB) software supported
The ProSoft Technology 1452-25M Ethernet/IP Module is meticulously designed for optimizing remote rack implementations. Its Windows-based graphical user interface, ProSoft Configuration Builder (PCB), simplifies both product and network configuration. This module leverages sample ladder logic and Add-On Instructions (AOIs) to facilitate smooth data transfer between the module and processor. Additionally, it features an internal web server that provides access to comprehensive product documentation, real-time module status, diagnostic insights, and firmware updates, ensuring optimal performance and ease of maintenance.
The module boasts a user-friendly 4-character alphanumeric scrolling LED display that clearly shows status and diagnostics data in plain English, eliminating the need to decipher cryptic error or alarm codes. Furthermore, the ProSoft Discovery Service (PDS) enhances the module’s utility by offering advanced diagnostics and monitoring capabilities, making it an indispensable tool for industrial automation systems.
